CAD Cleaning and Diagnostics

The CENTAUR CAD converter imports a CAD model in IGES, STEP or STL format and allows the user to prepare the geometry for grid generation. The CAD converter evaluates the quality of the imported CAD geometry, diagnoses problematic areas and provides fixes using both automatic and manual techniques.

CAD Diagnostics

• Easily identify CAD flaws
• Prevent meshing problems

Automatic CAD Cleaning

• Fix CAD errors
• Correct geometry within given tolerance

Manual CAD Cleaning

• Create missing CAD surfaces
• Remove features from geometry
